P2 Tx Multicast Frame Count Register

Address: 0xDA, Reset: 0x00000000, Name: P2_TX_MCAST_CNT

Table 136. Bit Descriptions for P2_TX_MCAST_CNT

Bits

Bit Name

Description

Reset

Access

[31:0]

P2_TX_MCAST_CNT

Tx Multicast Frame Count.

0x0

P2 Tx Unicast Frame Count Register

Address: 0xDB, Reset: 0x00000000, Name: P2_TX_UCAST_CNT

Table 137. Bit Descriptions for P2_TX_UCAST_CNT

Bits

Bit Name

Description

Reset

Access

[31:0]

P2_TX_UCAST_CNT

Tx Unicast Frame Count.

0x0

P2 Rx Frames Dropped Due to FIFO Full Register

Address: 0xDC, Reset: 0x00000000, Name: P2_RX_DROP_FULL_CNT

Table 138. Bit Descriptions for P2_RX_DROP_FULL_CNT

Bits

Bit Name

Description

Reset

Access

[31:0]

P2_RX_DROP_FULL_CNT

Rx Frames Dropped Due to FIFO Full. Note that on LES, if a received frame is destined for

both the host and other port (a flooded frame), and the frame is not forwarded to one of the

destination FIFOs because it is full, the frame is not counted as a dropped frame. That is, if

the frame is flooded, the P2_RX_DROP_FULL_CNT only increments if both FIFOs are full.

0x0

P2 Rx Frames Dropped Due to Filtering Register

Address: 0xDD, Reset: 0x00000000, Name: P2_RX_DROP_FILT_CNT

Table 139. Bit Descriptions for P2_RX_DROP_FILT_CNT

Bits

Bit Name

Description

Reset

Access

[31:0]

P2_RX_DROP_FILT_CNT

Rx Frames Dropped Due to Filtering.

0x0

Frames Received on Port 2 with IFG Errors Register

Address: 0xDE, Reset: 0x00000000, Name: P2_RX_IFG_ERR_CNT

Table 140. Bit Descriptions for P2_RX_IFG_ERR_CNT

Bits

Bit Name

Description

Reset

Access

[31:0]

P2_RX_IFG_ERR_CNT

IFG Error Counter for Port 2 Received Frames.

0x0

P2 Transmit Interframe Gap Register

Address: 0xE0, Reset: 0x0000000B, Name: P2_TX_IFG

Table 141. Bit Descriptions for P2_TX_IFG

Bits

Bit Name

Description

Reset

Access

[31:8]

RESERVED

Reserved.

0x0

[7:0]

P2_TX_IFG

Interframe Gap. Generates an IFG of (P2_TX_IFG + 1) × 8 bit times between frames on Tx.

0xB

R/W
