background image
Low-Power, Multifunction, Polyphase AFE
with Harmonics and Tamper Detect
98
______________________________________________________________________________________
Fundamental Apparent Power, Phase A/B/C/T (PWRSF.X)
(A: 0x8A1, B: 0x8A2, C: 0x8A4, T: 0x8A7)
This register contains the instantaneous apparent power delivered into phase A/B/C or total at the fundamental line
frequency only. Power is calculated from the instantaneous energy measurement according to the following equation:
Fundamental Real Energy, Phase A/B/C/T (ENRPF.X)
(A: 0x8E1, B: 0x8E2, C: 0x8E4, T: 0x8E7)
This signed register contains the real accumulated energy delivered into phase A/B/C or total. The register is calcu-
lated according to the following formula:
ENRPF.X = ENR_CC x (X.EAFPOS - X.EAFNEG)
Fundamental Reactive Energy, Phase A/B/C/T (ENRQF.X)
(A: 0x8F1, B: 0x8F2, C: 0x8F4, T: 0x8F7)
This signed register contains the reactive accumulated energy delivered into phase A/B/C or total. The register is
calculated according to the following formula:
ENRQF.X = ENR_CC x (X.ERFPOS - X.ERFNEG)
PWRSF X
X APPF
PWR CC
NS
.
._
=
×× 216
Byte 7 (MSByte unused)
Byte 6 (unused)
Byte 5
Byte 4
Byte 3
Byte 2
Byte 1
Byte 0 (LSByte)
Byte 7 (MSByte unused)
Byte 6 (unused)
Byte 5
Byte 4
Byte 3
Byte 2
Byte 1
Byte 0 (LSByte)
Byte 7 (MSByte unused)
Byte 6 (unused)
Byte 5
Byte 4
Byte 3
Byte 2
Byte 1
Byte 0 (LSByte)
