Low-Power, Multifunction, Polyphase AFE
with Harmonics and Tamper Detect
80
______________________________________________________________________________________
Line Cycle Averaging Filter (AVG_NS) (0x02E)
This register determines whether the NS value is averaged over previous values or whether the most recently measured
value is used directly. If the value of this register is nonzero, the NS value is averaged using the following formula:
If the value of this register is zero, NS is not averaged. The MSB of this register must be zero.
Meter Measurement Averaging Filter (AVG_C) (0x030)
This register determines whether the all other measured values in the electricity meter are averaged over time. If the
value of this register is nonzero, all measured meter values are averaged using the following formula:
If the value of this register is zero, no averaging is performed. The MSB of this register must be zero.
yy
AVG C
xy
nn
nn
=+
−
−
−
1
1
16
2
_
yy
AVG NS
xy
nn
nn
=+
−
−
−
1
1
16
2
_
Bit:
15
14
13
12
11
10
9
8
Name:
Meter Measurement Averaging Filter High Byte
Reset:
0x40
Bit:
7
6
5
4
3
2
1
0
Name:
Meter Measurement Averaging Filter Low Byte
Reset:
0x00
Bit:
15
14
13
12
11
10
9
8
Name:
Line Cycle Averaging Filter High Byte
Reset:
0x40
Bit:
7
6
5
4
3
2
1
0
Name:
Line Cycle Averaging Filter Low Byte
Reset:
0x00
