20 / 102 page ![]() Low-Power, Multifunction, Polyphase AFE with Harmonics and Tamper Detect 20 ______________________________________________________________________________________ During an SPI transfer, data is simultaneously transmit- ted and received over two serial data lines (MISO and MOSI) with respect to a single serial shift clock (SCLK). The polarity and phase of the serial shift clock are the primary components in defining the SPI data transfer format. The polarity of the serial clock corresponds to the idle logic state of the clock line and, therefore, also defines which clock edge is the active edge. To define a serial shift clock signal that idles in a logic-low state (active clock edge = rising), the clock polarity select (CKPOL; R_SPICF.0) bit should be configured to a 0, while setting CKPOL = 1 causes the shift clock to idle in a logic-high state (active clock edge = falling). The phase of the serial clock selects which edge is used to sample the serial shift data. The clock phase select (CKPHA; R_SPICF.1) bit controls whether the active or inactive clock edge is used to latch the data. When CKPHA is set to a logic 1, data is sampled on the inac- tive clock edge (clock returning to the idle state). When CKPHA is set to a logic 0, data is sampled on the active clock edge (clock transition to the active state). Together, the CKPOL and CKPHA bits allow four possi- ble SPI data transfer formats. Transfers over the SPI interface always start with the most significant bit and end with the least significant bit. All SPI data transfers to and from the MAXQ3183 are always 8 bits (one byte) in length. The MAXQ3183 SPI interface does not support 16-bit character lengths. The default format (upon power-up or system reset) for the MAXQ3183 SPI interface is represented in Figure 4a (CKPOL = 0; CKPHA = 0). In this format, the SCLK CYCLE # (FOR REFERENCE) SCLK (CKPOL = 0) SCLK (CKPOL = 1) MOSI (FROM MASTER) MISO (FROM SLAVE) SSEL (TO SLAVE) 1 MSB 6 5 4 3 2 1 LSB 2 3 4 5 6 7 8 6 MSB *NOT DEFINED BUT NORMALLY MSB OF CHARACTER JUST RECEIVED. 5 4 3 2 1 LSB * 1 MSB 6 5 4 3 2 1 LSB 2 3 4 5 6 7 8 MSB * *NOT DEFINED BUT NORMALLY LSB OF PREVIOUSLY TRANSMITTED CHARACTER. 6 5 4 3 2 1 LSB SCLK CYCLE # (FOR REFERENCE) SCLK (CKPOL = 0) SCLK (CKPOL = 1) MOSI (FROM MASTER) MISO (FROM SLAVE) SSEL (TO SLAVE) Figure 4b. SPI Interface Timing (CKPHA = 1) Figure 4a. SPI Interface Timing (CKPHA = 0) |
|
