26 / 102 page  Low-Power, Multifunction, Polyphase AFE with Harmonics and Tamper Detect 26 ______________________________________________________________________________________ Table 3. RAM Register Map x0h x1h x2h x3h x4h x5h x6h x7h x8h x9h xAh xBh xCh xDh xEh xFh 0x00 STATUS OP MODE0 OP MODE1 OP MODE2 IRQ_FLAG IRQ_MASK SCAN _IA SCAN _VA SCAN _IC SCAN _VC SCAN _IB SCAN _VB SCAN _IN SCAN _TE 0x01 AUX_CFG SYS_KHZ VOLT_CC AMP_CC PWR_CC ENR_CC CYCNT PLSCFG 1 PLSCFG 2 0x02 PLS1_WD THR1 PLS2_WD THR2 REJ_NS AVG_NS 0x03 AVG_C HPF_C B0FUND A1FUND B0HARM A1HARM 0x04 NS OCLVL OVLVL UVLVL NOLOAD R_ACFG R_ADCRATE 0x05 R_ADCACQ R_ SPICF ISUMLVL COM_TIMO ACC_TIMO ZC_LPF I1THR I2THR 0x06 TEMP_CC LINEFR CHKSUM 0x11 N.IRMS 0x12 N.I_GAIN PHASE A CALIBRATION AND STATUS REGISTERS 0x13 A.I_GAIN A.V_GAIN A.E_GAIN A.EF_GAIN A.OFFS_HI A.GAIN_LO A.OFFS_LO A.PA0 0x14 A.PA1 A.PA2 A. FLAGS A. MASK A. EOVER A. EFOVER PHASE B CALIBRATION AND STATUS REGISTERS 0x21 B.I_GAIN B.V_GAIN 0x22 B.E_GAIN B.EF_GAIN B.OFFS_HI B.GAIN_LO B.OFFS_LO B.PA0 B.PA1 B.PA2 0x23 B. FLAGS B. MASK B. EOVER B. EFOVER PHASE C CALIBRATION AND STATUS REGISTERS 0x30 C.I_GAIN C.V_GAIN C.E_GAIN C.EF_GAIN 0x31 C.OFFS_HI C.GAIN_LO C.OFFS_LO C.PA0 C.PA1 C.PA2 C. FLAGS C. MASK C. EOVER C. EFOVER 0x32 PHASE A MEASUREMENT REGISTERS* 0x1C A.PF A.VRMS A.IRMS 0x1D A.ACT A.REA A.APP A.ACTF 0x1E A.REAF A.APPF A.EAPOS A.EANEG 0x1F A.ERPOS A.ERNEG A.ES A.EAFPOS 0x20 A.EAFNEG A.ERFPOS A.ERFNEG A.ESF PHASE B MEASUREMENT REGISTERS* 0x2B B.PF B.VRMS B.IRMS B.ACT 0x2C B.REA B.APP B.ACTF B.REAF 0x2D B.APPF B.EAPOS B.EANEG B.ERPOS 0x2E B.ERNEG B.ES B.EAFPOS B.EAFNEG 0x2F B.ERFPOS B.ERFNEG B.ESF PHASE C MEASUREMENT REGISTERS* 0x39 C.PF 0x3A C.VRMS C.IRMS C.ACT C.REA 0x3B C.APP C.ACTF C.REAF C.APPF 0x3C C.EAPOS C.EANEG C.ERPOS C.ERNEG 0x3D C.ES C.EAFPOS C.EAFNEG C.ERFPOS 0x3E C.ERFNEG C.ESF * Read-only. |
|
