background image
Low-Power, Multifunction, Polyphase AFE
with Harmonics and Tamper Detect
______________________________________________________________________________________
45
Energy, Real Negative, Phase X = A/B/C (X.EANEG)
(A: 0x1EC, B: 0x2D8, C: 0x3C4)
On every DSP cycle, the contents of the X.ACT register are tested, and, if negative, absolute values are added to
this register. When this register overflows, the ANOV bit in the X.EOVER register is set.
Energy, Reactive Positive, Phase X = A/B/C (X.ERPOS)
(A: 0x1F0, B: 0x2DC, C: 0x3C8)
On every DSP cycle, the contents of the X.REA register are tested, and, if positive, are added to this register. When
this register overflows, the RPOV bit in the X.EOVER register is set.
Bit:
31
30
29
28
27
26
25
24
Name:
Real Energy Byte 3
Bit:
23
22
21
20
19
18
17
16
Name:
Real Energy Byte 2
Bit:
15
14
13
12
11
10
9
8
Name:
Real Energy Byte 1
Bit:
7
6
5
4
3
2
1
0
Name:
Real Energy Byte 0
Bit:
31
30
29
28
27
26
25
24
Name:
Reactive Energy Byte 3
Bit:
23
22
21
20
19
18
17
16
Name:
Reactive Energy Byte 2
Bit:
15
14
13
12
11
10
9
8
Name:
Reactive Energy Byte 1
Bit:
7
6
5
4
3
2
1
0
Name:
Reactive Energy Byte 0
