Low-Power, Multifunction, Polyphase AFE
with Harmonics and Tamper Detect
______________________________________________________________________________________
75
Time Slot Assignment—Neutral Current Channel (SCAN_IN) (0x00E)
This register configures the time slot normally assigned to the neutral current channel. The user can change the
DADCNV bit to enable/disable neutral current sampling. It is recommended to leave the other bits of this register at
their default values.
Bit:
7
6
5
4
3
2
1
0
Name:
ADCMX
DADCNV
—
—
—
Reset:
0x6
1
0
0
0
BIT
NAME
FUNCTION
7:4
ADCMX
Analog Conversion Select. This four-bit field determines which of the following analog inputs are sampled
during this time slot. All other values are reserved. By default, this register is set to 0110.
0000 = V0P - VN
0001 = V1P - VN
0010 = V2P - VN
0011 = I0P - I0N
0100 = I1P - I1N
0101 = I2P - I2N
0110 = INP - VN
1xxx = Temperature
3
DADCNV ADC Disable. When set, disables the ADC for this time slot.
2:0
—
Reserved.
