Low-Power, Multifunction, Polyphase AFE

with Harmonics and Tamper Detect

______________________________________________________________________________________

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional

operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to

absolute maximum rating conditions for extended periods may affect device reliability.

Voltage Range on DVDD Relative to DGND .........-0.3V to +4.0V

Voltage Range on AVDD Relative to AGND..........-0.3V to +4.0V

Voltage Range on AGND Relative to DGND .........-0.3V to +0.3V

Voltage Range on AVDD Relative to DVDD ..........-0.3V to +0.3V

Voltage Range on Any Pin Relative to

DGND except VxP, IxN Pins..............................-0.3V to +4.0V

Voltage Range on VxP, IxN Relative to AGND ......-0.3V to +4.0V

Operating Temperature Range ...........................-40°C to +85°C

Junction Temperature ......................................................+150°C

Storage Temperature Range .............................-65°C to +150°C

Lead Soldering Temperature .............................Refer to the IPC/

JEDEC J-STD-020 Specification.

PARAMETER

CONDITIONS

MIN

TYP

MAX

UNITS

Active Energy Linearity Error

DR 1000:1

0.1

Reactive Energy Linearity Error

DR 1000:1

0.2

Apparent Energy Linearity Error

DR 1000:1

0.5

RMS Voltage Linearity Error

DR 20:1

0.5

DR 500:1

1.0

RMS Current Linearity Error

DR 20:1

0.5

Line Frequency Error

0.5

Power Factor Error

1.0

ELECTRICAL CHARACTERISTICS

(VAVDD = VDVDD = VRST to 3.6V, TA = -40°C to +85°C, unless otherwise noted.) (Note 2)

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

POWER-SUPPLY SPECIFICATIONS

Digital Supply Voltage

VDVDD

VRST

3.6

Power-Fail Interrupt Trip Point

VPFW

Active mode, EPWRF = 1

2.84

3.13

Power-Fail Reset Trip Point

VRST

Active mode

2.70

2.99

Analog Supply Voltage

VAVDD

VRST

3.6

Analog Supply Current

IAVDD

fCLK = 8MHz

0.9

1.8

Digital Supply Current

IDVDD

fCLK = 8MHz

8.5

Low-Power Measurement Mode

Current

ILOWPM

LOWPM = 1 (Note 1)

4.2

Stop-Mode Current

0.2

μA

DIGITAL I/O SPECIFICATIONS

Input High Voltage

VIH

0.7 x

VDVDD

Input Low Voltage

VIL

0.3 x

VDVDD

Input Hysteresis

VIHYS

VDVDD = 3.3V

500

Input Leakage

VIN = DGND or VDVDD, pullup off

±0.01

±1

μA

METERING SPECIFICATIONS

(VAVDD = VDVDD = VRST to 3.6V, Current Channel Dynamic Range 1000:1 at TA = +25°C, unless otherwise noted.) (Note 1)

ABSOLUTE MAXIMUM RATINGS
