Low-Power, Multifunction, Polyphase AFE
with Harmonics and Tamper Detect
______________________________________________________________________________________
37
CFQ Pulse Threshold (THR2) (0x028)
This register designates the threshold of the CFQ pulse. This value is used to set the meter constant for the CFQ
pulse output. When the CFQ pulse accumulator exceeds the value set in this register, the CFQ pulse output is acti-
vated and the CFQ pulse accumulator is reduced by the amount in this register.
Calibration Registers
Current Gain, Phase X = A/B/C/N (X.I_GAIN) (A: 0x130, B: 0x21C, C: 0x308, N: 0x12E)
This register contains gain coefficient for phase X current channel. The raw values are taken from the selected mea-
surement quantity and scaled by the factor:
Note: Bit 15 of this register must be set to zero for correct operation.
X I GAIN
._
214
Bit:
31
30
29
28
27
26
25
24
Name:
THR2 Byte 3
Reset:
0x00
Bit:
23
22
21
20
19
18
17
16
Name:
THR2 Byte 2
Reset:
0x10
Bit:
15
14
13
12
11
10
9
8
Name:
THR2 Byte 1
Reset:
0x00
Bit:
7
6
5
4
3
2
1
0
Name:
THR2 Byte 0
Reset:
0x00
Bit:
15
14
13
12
11
10
9
8
Name:
Current Gain Coefficient High Byte
Reset:
0x40
Bit:
7
6
5
4
3
2
1
0
Name:
Current Gain Coefficient Low Byte
Reset:
0x00
