background image
Low-Power, Multifunction, Polyphase AFE
with Harmonics and Tamper Detect
36
______________________________________________________________________________________
CFP Pulse Threshold (THR1) (0x022)
This register designates the threshold of the CFP pulse. This value is used to set the meter constant for the CFP
pulse output. When the CFP pulse accumulator exceeds the value set in this register, the CFP pulse output is activat-
ed and the CFP pulse accumulator is reduced by the amount in this register.
CFQ Pulse Width (PLS2_WD) (0x026)
This register designates the width of the CFQ pulse; that is, the duration of the period that the CFQ pulse is in the
active state. This value is given in ADC frame times (about 360μs). The default value of 0x9C (156 decimal) provides
a pulse width of about 50ms.
Bit:
31
30
29
28
27
26
25
24
Name:
THR1 Byte 3
Reset:
0x00
Bit:
23
22
21
20
19
18
17
16
Name:
THR1 Byte 2
Reset:
0x10
Bit:
15
14
13
12
11
10
9
8
Name:
THR1 Byte 1
Reset:
0x00
Bit:
7
6
5
4
3
2
1
0
Name:
THR1 Byte 0
Reset:
0x00
Bit:
15
14
13
12
11
10
9
8
Name:
CFQ Pulse-Width High Byte
Reset:
0x00
Bit:
7
6
5
4
3
2
1
0
Name:
CFQ Pulse-Width Low Byte
Reset:
0x9C
