Low-Power, Multifunction, Polyphase AFE
with Harmonics and Tamper Detect
______________________________________________________________________________________
11
ELECTRICAL CHARACTERISTICS (continued)
(VAVDD = VDVDD = VRST to 3.6V, TA = -40°C to +85°C, unless otherwise noted.) (Note 2)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Input Low Current
IIL
VIN = 0.4V, weak pullup on
-50
μA
RESET Pullup Resistance
RRESET
50
150
200
k
IOH = -4mA
VDVDD
- 0.4
Output High Voltage (Except
RESET)
VOH
IOH = -6mA
VDVDD
- 0.5
V
IOL = 4mA
0.4
Output Low Voltage
VOL
IOL = 6mA
0.5
V
SYSTEM CLOCK SOURCES
External Clock Input Frequency
0
8.12
MHz
External Clock Input Duty Cycle
45
55
%
External HF Crystal Frequency
fSYS
Fundamental mode
8.12
MHz
XTAL1, XTAL2 Internal Load
Capacitance
16
pF
Internal RC Oscillator Frequency
7.4
7.6
8.6
MHz
Internal RC Oscillator Accuracy
±2
%
Internal RC Oscillator Current
50
120
μA
Internal RC Oscillator Startup
Delay
(Note 1)
0.45
μs
ANALOG-TO-DIGITAL CONVERTER
Input Voltage Range
0
VREF
V
Common-Mode Bias
VCOMM
1.14
V
Offset Error
±2
mV
Offset Error Drift
±8
μV/
°C
Gain Error (G = 1)
0.05
%
Spurious-Free Dynamic Range
SFDR
90
dB
Total Harmonic Distortion
THD
90
dB
Input Bandwidth (-3dB)
(Note 1)
7
kHz
INTERNAL VOLTAGE REFERENCE
Temperature Coefficient
(Note 1)
30
ppm/
°C
Output Voltage
VREF
2.048
V
INTERNAL TEMPERATURE SENSOR
Temperature Error
(Note 1)
-4
+4
°C
SPI SLAVE-MODE INTERFACE TIMING
Maximum SPI Clock Rate
fSYS/4
MHz
SCLK Input Pulse-Width High
tSCH
(Note 3)
4 x
tSYS
ns
SCLK Input Pulse-Width Low
tSCL
(Note 3)
4 x
tSYS
ns
