Low-Power, Multifunction, Polyphase AFE
with Harmonics and Tamper Detect
______________________________________________________________________________________
73
Advanced Register Configurations
Analog Scan Configuration Registers
Time Slot Assignment—Current Channel X = A/B/C (SCAN_IX)
(A: 0x008, B: 0x00C, C: 0x00A)
These registers configure the time slot normally assigned to current channels A/B/C. We recommend leaving these
registers at their default values. If they must be reassigned, one must ensure that all the current and voltage chan-
nels are reassigned properly so that the MAXQ3183 computes the power/energy parameters as intended by your
setup.
Bit:
7
6
5
4
3
2
1
0
Name:
ADCMX
DADCNV
—
—
—
Reset A:
0x3
0
0
0
0
Reset B:
0x4
0
0
0
0
Reset C:
0x5
0
0
0
0
BIT
NAME
FUNCTION
7:4
ADCMX
Analog Conversion Select. This four-bit field determines which of the following analog inputs are
sampled during this time slot.
0000 = V0P - VN
0001 = V1P - VN
0010 = V2P - VN
0011 = I0P - I0N (Phase A Current: 0011)
0100 = I1P - I1N (Phase B Current: 0100)
0101 = I2P - I2N (Phase C Current: 0101)
0110 = INP - VN
1xxx = Temperature
All other values are reserved.
3
DADCNV
ADC Disable. When set, disables the ADC for this time slot.
2:0
—
Reserved.
