background image
Low-Power, Multifunction, Polyphase AFE
with Harmonics and Tamper Detect
76
______________________________________________________________________________________
Time Slot Assignment—Temperature Channel (SCAN_TE) (0x00F)
This register configures the time slot normally assigned to the temperature measurement device. This register is
managed by the firmware and should not be modified by the host.
BIT
NAME
FUNCTION
7:4
ADCMX
Analog Conversion Select. This four-bit field determines which of the following analog inputs are
sampled during this time slot.
0000 = V0P - VN
0001 = V1P - VN
0010 = V2P - VN
0011 = I0P - I0N
0100 = I1P - I1N
0101 = I2P - I2N
0110 = INP - VN
0111 = Auto-zero ADC
1xxx = Temperature
By default, this register is set to 1000.
3
DADCNV
ADC Disable. When set, disables the ADC for this time slot.
2:0
PGG
Programmable Gain Amplifier Select. This three-bit field configures the programmable-gain amplifier at
the front end of the analog input. The field has the following values:
000 = Gain of 1
001 = Gain of 2
010 = Gain of 4
011 = Gain of 8
100 = Gain of 16
101 = Gain of 32
All other values are reserved and can cause unpredictable behavior if selected. This register is
managed by the firmware and should not be modified by the host.
Bit:
7
6
5
4
3
2
1
0
Name:
ADCMX
DADCNV
PGG
Reset:
0x8
1
0x2
