 83 / 102 page
background image
Low-Power, Multifunction, Polyphase AFE
with Harmonics and Tamper Detect
______________________________________________________________________________________
83
Harmonic Filter Feedback Coefficient (A1HARM) (0x03C)
This register specifies the a1 (feedback) coefficient for the harmonic mode filter using the following formula:
Zero-Cross Lowpass Filter (ZC_LPF) (0x05A)
This register specifies the lowpass filter applied for zero-cross detection. The MSB of this register must be zero.
a
A HARM
1
16
1
2
=
Bit:
31
30
29
28
27
26
25
24
Name:
Harmonic Filter Feedback Coefficient Byte 3
Reset:
0x00
Bit:
23
22
21
20
19
18
17
16
Name:
Harmonic Filter Feedback Coefficient Byte 2
Reset:
0x00
Bit:
15
14
13
12
11
10
9
8
Name:
Harmonic Filter Feedback Coefficient Byte 1
Reset:
0x18
Bit:
7
6
5
4
3
2
1
0
Name:
Harmonic Filter Feedback Coefficient Byte 0
Reset:
0x31
Bit:
15
14
13
12
11
10
9
8
Name:
Zero-Cross Lowpass Filter High Byte
Reset:
0x0B
Bit:
7
6
5
4
3
2
1
0
Name:
Zero-Cross Lowpass Filter Low Byte
Reset:
0x00
