13 / 84 page  Data Sheet ADP1053 Rev. A | Page 13 of 84 ACSNS CS1_A VIN = 36V DC TO 60V DC Q1 Q2 Q3 Q4 Q6 Q7 Q8 Q5 DRIVER DRIVER VDD = 10V VDD = 10V DRIVER VDD = 10V DRIVER VDD = 10V DRIVER VDD = 10V 3:5 OUT1 OUT3 OUT4 OUT2 OUT5 OUT7 ADP1053 OUT6 OUT8 CS2–_A CS2+_A VS+_A VS–_A CS1_A ACSNS CS2–_B CS2+_B VS–_B VS+_B iCoupler 3.3V 5V iCoupler 3.3V 5V LOAD LOAD VOUT A+ 48V/4A VOUT A– VOUT B+ 24V/5A VOUT B– Q9 Q10 Figure 6. Application Circuit 2—Two Output Channels with Only One Full-Bridge Rectifier |
|
