Data Sheet

ADP1053

Rev. A | Page 57 of 84

Table 48. Register 0xFE18 and Register 0xFE19—CS2_A OCP Threshold and CS2_B OCP Threshold

Bits

Bit Name

R/W

Description

[7:0]

CS2_A/CS2_B OCP

threshold

R/W

The 8-bit OCP threshold set in this register is compared with Bits[15:8] in the CS2_A or CS2_B

value register (Register 0xFED3 or Register 0xFED4). If the eight MSBs in the value register are

higher, the CS2_A_OCP or CS2_B_OCP flag is set. When the OCP threshold is set to 0xFF (255

decimal), the CS2_A_OCP or CS2_B_OCP flag is always cleared. The range of the CS2 ADC is

0 mV to 120 mV, so the step size is 120 mV/4096 = 29.3 μV. Therefore, the threshold step size

is 29.3 μV × 16 = 468.8 μV. The OCP threshold can be calculated as follows:

Threshold Target (V) = (Threshold Code + 1) × 468.8 μV

The GUI converts the voltage to current based on the value of the current sensing resistor.

The valid range of the register code is from 2 to 241 decimal.

Register 0xFE1A selects the CS2_A high-side/low-side setting, sets the CS2_A_OCP flag debounce time, and sets the light load threshold

for Channel A. Register 0xFE1B sets the same values for Channel B.

Table 49. Register 0xFE1A and Register 0xFE1B—CS2_A/CS2_B High-Side/Low-Side Setting and Channel A/Channel B Light Load

Threshold

Bits

Bit Name

R/W

Description

High-side/low-side

sensing

R/W

This bit configures the part for high-side resistor current sensing or low-side current sensing.

0 = CS2_A or CS2_B is configured for low-side sensing.

1 = CS2_A or CS2_B is configured for high-side sensing.

These bits set the CS2_A_OCP/CS2_B_OCP flag debounce time.

Bit 6

Bit 5

Typical Debounce Time

0 ms

20 ms

200 ms

[6:5]

CS2_A_OCP/CS2_B_

OCP flag debounce

R/W

1 sec

LIGHTLOAD_A/

LIGHTLOAD_B flag

blanking in soft start

R/W

This bit specifies whether to blank the LIGHTLOAD_A/LIGHTLOAD_B flag during soft start.

0 = do not blank the LIGHTLOAD_A/LIGHTLOAD_B flag during Channel A/Channel B soft start.

1 = blank the LIGHTLOAD_A/LIGHTLOAD_B flag during Channel A/Channel B soft start.

[3:0]

CS2_A/CS2_B light

load threshold

R/W

These bits set the CS2_A/CS2_B ADC light load threshold value, below which the LIGHTLOAD_A or

LIGHTLOAD_B flag is set and Channel A or Channel B enters light load mode. Each LSB corresponds

to 64 LSBs of the 12-bit CS2_A/CS2_B reading, which is 1.56% of the full range (1.875 mV). Hysteresis

is included to exit light load mode; the threshold to exit light load mode is 96 LSBs greater than

the threshold to enter light load mode (96 LSBs = 2.34% of the full range, that is, 2.8125 mV).

When these bits are set to 0, the LIGHTLOAD_A/LIGHTLOAD_B flag is always cleared.

CHANNEL A/CHANNEL B VOLTAGE SENSE AND LIMIT SETTING REGISTERS

Table 50. Register 0xFE1C—VS_A Gain Trim

Bits

Bit Name

R/W

Description

Trim polarity

R/W

1 = negative gain is introduced.

0 = positive gain is introduced.

[6:0]

VS_A gain trim

R/W

These bits set the amount of gain trim that is applied to the VS_A ADC reading. This register

trims the voltage at the VS_A pin for external resistor tolerances. For more information, see the

VS_A and VS_B Gain Trim section.

Table 51. Register 0xFE1D—VS_B Gain Trim

Bits

Bit Name

R/W

Description

Trim polarity

R/W

1 = negative gain is introduced.

0 = positive gain is introduced.

[6:0]

VS_B gain trim

R/W

These bits set the amount of gain trim that is applied to the VS_B ADC reading. This register

trims the voltage at the VS_B pin for external resistor tolerances. For more information, see the

VS_A and VS_B Gain Trim section.
