ADP1053
Data Sheet
Rev. A | Page 6 of 84
Parameter
Test Conditions/Comments
Min
Typ
Max
Unit
AC SENSE
Input Voltage
Voltage from ACSNS to AGND
0
1
1.6
V
Input Voltage FSR
1.6
V
ACSNS ADC
Valid Input Voltage Range
0
1
1.4
V
ADC Register Update Rate
800
Hz
Resolution
11
Bits
Measurement Accuracy
From 10% to 90% of valid input voltage
−1.25
+1.8
% FSR
−20
+28.8
mV
From 0% to 100% of valid input voltage
−5.4
+1.9
% FSR
−86.4
+30.4
mV
ACSNS
Threshold Accuracy
Same as ACSNS ADC measurement
accuracy specifications
Comparator Update Speed
1
ms
CS, CS1_A, CS1_B CURRENT SENSE
Input Voltage
Voltage from CS/CS1_A/CS1_B to AGND
0
1.6
V
Input Voltage FSR
1.6
V
CS, CS1_A, CS1_B ADCs
Valid Input Voltage Range
0
1
1.4
V
ADC Register Update Rate
100
Hz
Resolution
12
Bits
Measurement Accuracy
From 10% to 90% of valid input voltage
−1.3
+1.8
% FSR
−20.8
+28.8
mV
From 0% to 100% of valid input voltage
−5.6
+1.8
% FSR
−89.6
+28.8
mV
Fast OCP
Threshold Value
1.18
1.2
1.22
V
Propagation Delay (Latency)
Debounce/blanking time not included
58
110
ns
CS2_A, CS2_B CURRENT SENSE
Input Voltage
Differential voltage from CS2+_A to
CS2−_A and from CS2+_B to CS2−_B
0
120
mV
Input Voltage FSR
120
mV
Common-Mode Voltage
Common-mode voltage from CS2+_A/
CS2−_A and CS2+_B/CS2−_B to AGND
to achieve measurement accuracy
0.8
1
1.3
V
CS2_A, CS2_B ADCs
Valid Input Voltage Range
0
120
mV
Resolution
12
Bits
Measurement Accuracy
Low-Side Mode with User Trim
VOUT = 0 V, 5 kΩ level-shifting resistor
From 0 mV to 110 mV
−1.85
+2.1
% FSR
−2.22
+2.52
mV
From 110 mV to 120 mV
−6.1
+1.5
% FSR
−6.36
+0.84
mV
High-Side Mode with User Trim
VOUT = 11 V, 5 kΩ level-shifting resistor
From 0 mV to 110 mV
−1.6
+2.3
% FSR
−1.92
+2.76
mV
From 110 mV to 120 mV
−5.3
+0.7
% FSR
−6.36
+0.84
mV
