control via a GPIO must be used to select the media converter

operation in RMII mode.

Table 16. Media Converter Selection (Hardware Configuration)

MEDIA_CNV

Media Converter Selection

Normal PHY operation

Media converter operation

PHY Address Configuration

The ADIN1101 PHY address can be configured using three pins:

►

RXD_2/PHYAD_0

►

RXD_3/PHYAD_1

►

LINK_ST/PHYAD_2

These are two-level configuration pins, which means that it is possi-

ble to configure the ADIN1101 to any of the eight available PHY

addresses. The PHY address pins have weak internal pull-down

resistors. Thus, by default, the ADIN1101 is configured with PHY

Address 0x0.

Particular attention is required if these three pins are used in

managed applications and connected to an external host controller

because the PHY address is set after power-up, hardware reset, or

software reset.

Software Power-Down After Reset

The SWPD_EN hardware configuration pin signal is shared with the

RX_DV signal and is used to enable or disable the software pow-

er-down after reset feature. The power-down bit (CRSM_SFT_PD)

is set based on the SWPD_EN signal status during power-up,

hardware reset, or software reset. CRSM_SFT_PD can also be

set using the MDIO interface to enable software power-down after

reset.

The RX_DV/RX_CTL/SWPD_EN pin has a weak internal pull-down

resistor. Thus, by default, the ADIN1101 is configured with software

power-down after reset enabled.

When software power-down after reset is enabled, the ADIN1101

enters software power-down after power-up, hardware reset, or

software reset. Software power-down provides a lower power mode

where most of the ADIN1101 internal modules are turned off.

The ADIN1101 can be configured to exit power-down by setting the

CRSM_SFT_PD bit to 0 using the MDIO interface.

Following a power-up, hardware reset, or software reset, and if

autonegotiation is enabled and software power-down after reset is

disabled, the ADIN1101 starts autonegotiation and tries to bring up

a link.

Table 17. Software Power-Down (Hardware Configuration)

SWPD_EN

Software Power-Down Configuration

PHY in software power-down after reset

PHY not in software power-down after reset

Leader/Follower Preference

The MS_SEL hardware configuration pin signal is shared with the

RXD_1 signal and configures the default leader/follower selection.

If MS_SEL is pulled low during power-up, hardware reset, or soft-

ware reset, the device is configured by default to prefer follower.

If MS_SEL is pulled high during power-up, hardware reset, or

software reset, the device is configured by default to prefer leader.

The RXD_1/MS_SEL pin has a weak internal pull-down resistor.

Thus, by default, the ADIN1101 is configured to prefer follower.

The MS_SEL hardware configuration pin signal configures the

default setting of the autonegotiation leader/follower configuration

setting of the leader/follower configuration register bit (CFG_MST),

which is used when autonegotiation is disabled.

The AN_ADV_MST and CFG_MST bits can be modified using the

MDIO interface but return to their default values set by the MS_SEL

hardware configuration pin signal after power-up, hardware reset,

or software reset.

Table 18. Leader/Follower Selection (Hardware Configuration)

MS_SEL

Leader/Follower Selection

Prefer follower selection

Prefer leader selection

Transmit Amplitude

The TX2P4_EN hardware configuration pin signal is shared with

the RXD_0 signal and is used to configure the default transmit

amplitude mode. The transmit amplitude mode is defined by the

pin status during power-up, hardware reset, or software reset as

defined in Table 19.

The TX2P4_EN hardware configuration pin signal configures

the default setting of the high voltage transmit ability bit

(B10L_TX_LVL_HI_ABLE).

The RXD_0/TX2P4_EN pin has a weak internal pull-down resistor.

Thus, by default, the ADIN1101 is configured to support both 1.0 V

p-p and 2.4 V p-p voltage levels.

If the RXD_0/TX2P4_EN pin is strapped high (1.0 V p-p only), the

associated register cannot be changed through the MDIO interface.

That is, 2.4 V p-p operation is not possible if the ADIN1101 has

been hardware pin configured only for 1.0 V p-p.
