ADMV1455BBCZ-R7 datasheet(113/141 Pages) AD

113 / 141 page

Data Sheet

ADMV1455

analog.com

Rev. 0 | 113 of 141

Figure 240.

Table 90. Bit Descriptions for REG0218

Bits

Bit Name

Description

Reset

Access

[7:0]

FILTER_LUT_OUTPUT[63:56]

Filter LUT Output. This bit field represents the filter values as determined by the LUT prior to the mux

controlled by Register 0x202 and the LOAD feature.

0x0

Address: 0x219, Reset: 0x00, Name: REG0219

Figure 241.

Table 91. Bit Descriptions for REG0219

Bits

Bit Name

Description

Reset

Access

[7:0]

FILTER_LUT_OUTPUT[71:64]

Filter LUT Output. This bit field represents the filter values as determined by the LUT prior to the mux

controlled by Register 0x202 and the LOAD feature.

0x0

Address: 0x21A, Reset: 0x00, Name: REG021A

Figure 242.

Table 92. Bit Descriptions for REG021A

Bits

Bit Name

Description

Reset

Access

[7:0]

FILTER_LUT_OUTPUT[79:72]

Filter LUT Output. This bit field represents the filter values as determined by the LUT prior to the mux

controlled by Register 0x202 and the LOAD feature.

0x0

Address: 0x21B, Reset: 0x00, Name: REG021B

Figure 243.

Table 93. Bit Descriptions for REG021B

Bits

Bit Name

Description

Reset

Access

[7:0]

FILTER_LUT_OUTPUT[87:80]

Filter LUT Output. This bit field represents the filter values as determined by the LUT prior to the mux

controlled by Register 0x202 and the LOAD feature.

0x0
