background image
CC1010
SWRS047
Page 136 of 152
Symbol
Dimensions (mm)
Remarks
A
1.20 max
Overall height
A1
0.05 - 0.15
Standoff
A2
1.00
± 0.05
Package thickness
D
12.00
± 0.20
Terminal dimension
D1
9.95
± 0.10
Top package width
D3
10.00
± 0.10
Bottom package width
E
12.00
± 0.20
Terminal dimension
E1
9.95
± 0.10
Top package length
E3
10.00
± 0.10
Bottom package length
R1
0.08 Min
First radius
R2
0.15 Ref.
Second radius
β
0
° - 7°
Foot angle
β1
0
° Min
Shoulder angle
β2
12
°
Top draft angle
β3
12
°
Bottom draft angle
C
0.09 - 0.20
Lead thickness
L
0.60
± 0.15
Foot length
L1
1.0 Ref
Lead length
S
0.20 Min.
-
Ccc
0.080 Max
Coplanarity
Ddd
0.080 Max
Bent lead
e
0.50
Lead pitch
b
0.17 - 0.27
Lead tip width
Table 40. TQFP-64 package dimensions
21. Soldering Information
The recommended soldering profiles for both leaded and Pb-free packages are according to
IPC/JEDEC J-STD-020B, July 2002.
