CC1010

SWRS047

Page 36 of 152

PCON (0x87) - Power Control Register

Bit

Name

R/W

Reset value

Description

SMOD0

R/W

Serial Port 0 baud rate doubler enable.

0 : Serial Port 0 baud rate is not doubled

1 : Serial Port 0 baud rate is doubled

R/W

Reserved

Reserved, read as 1

GF1

R/W

General purpose flag 1. Bit-addressable, general

purpose flag for software control.

GF0

R/W

General purpose flag 0. Bit-addressable, general

purpose flag for software control.

STOP

R/W

Power Down (Stop) mode select. Setting the

STOP bit

places

CC1010 core and peripherals in Stop Mode.

IDLE

R/W

Idle mode select. Setting the

IDLE bit places CC1010

in Idle Mode (core is stopped but peripherals are

running).

X32CON (0xD1) - 32.768 kHz Crystal Oscillator Control Register

Bit

Name

R/W

Reset value

Description

Reserved, read as 0

X32_BYPASS R/W

32.768 kHz oscillator bypass control signal

0 : The internal 32.768 kHz oscillator is used to

generate the 32.768kHz clock

1 : The internal 32.768 kHz oscillator is bypassed, and

an external clock signal can be applied to the

XOSC32_Q1 pin.

X32_PD

R/W

32.768 kHz oscillator power down signal

0 : The oscillator is powered up

1 : The oscillator is powered down (default after reset)

CMODE

R/W

Select different Clock Modes for the 8051 and its

peripherals.

0 : Clock Mode 0 is selected (default after reset)

1 : Clock Mode 1 is selected
