CC1010

SWRS047

Page 87 of 152

Item

433 MHz

868 MHz

915 MHz

C31

10 pF, 5%, C0G, 0603

8.2 pF, 5%, C0G, 0603

C41

6.8 pF, 5%, C0G, 0603

Not used

C42

8.2 pF, 5%, C0G, 0603

10 pF, 5%, C0G, 0603

C171

18 pF, 5%, C0G, 0603

C181

18 pF, 5%, C0G, 0603

L32

68 nH, 10%, 0805

(Coilcraft 0805CS-680XKBC)

12 nH, 10%, 0805

(Coilcraft 0805CS-120XKBC)

12 nH, 10%, 0805

(Coilcraft 0805CS-120XKBC)

L41

6.2 nH, 10%, 0805

(Coilcraft 0805HQ-6N2XKBC)

2.5 nH, 10%, 0805

(Coilcraft 0805HQ-2N5XKBC)

2.5 nH, 10%, 0805

(Coilcraft 0805HQ-

2N5XKBC)

L101

27 nH, 5%, 0805

(Koa KL732ATE27NJ)

3.3 nH, 5%, 0805

(Koa KL732ATE3N3C)

3.3 nH, 5%, 0805

(Koa KL732ATE3N3C)

R131

82 k

Ω, 1%, 0603

82 k

Ω, 1%, 0603

82 k

Ω, 1%, 0603

XTAL

14.7456 MHz crystal,

16 pF load

14.7456 MHz crystal,

16 pF load

14.7456 MHz crystal,

16 pF load

Table 28. Bill of materials for the application circuit

Note: Shaded items are different for different frequencies

Note that the component values for 868

and 915 MHz can be the same. However,

it is important that the layout is optimised

for the selected VCO inductor in order to

centre the tuning range around the

operating

frequency

account

for

inductor tolerance. The VCO inductor must

be placed very close and symmetrical with

respect to the pins (L1 and L2).

Chipcon provides reference layouts that

should be followed very closely in order to

achieve

the

best

performance.

The

reference design can be downloaded from

the Chipcon website.
