background image
CC1010
SWRS047
Page 48 of 152
Alternate Function
Port
Available
pins
Normal operation
Flash Programming
P0.0
SCK, SPI Serial Clock output
SCK, SPI Serial Clock Input
P0.1
MO, SPI Master Output
SI, SPI Slave Input
P0.2
MI, SPI Master Input
SO, SPI Slave Output
P0
P0.3
-
-
P1.0
-
-
P1.1
-
-
P1.2
-
-
P1.3
-
-
P1.4
-
-
P1.5
-
-
P1.6
-
-
P1
P1.7
-
-
P2.0
RXD1, Serial port 1 input
-
P2.1
TXD1, Serial port 1 output
-
P2.2
-
-
P2.3
-
-
P2.4
-
-
P2.5
-
-
P2.6
-
-
P2
P2.7
-
-
P3.0
RXD0, Serial port 0 input
-
P3.1
TXD0, Serial port 0 output
-
P3.2
INT0 , External interrupt 0
-
P3.3
INT1 , External interrupt 1
-
P3.4
T0, Counter input 0 to Timer 0, or
PWM2, PWM output from Timer 2
-
P3
P3.5
T1, Counter input 1 to Timer 1, or
PWM3, PWM output from Timer 3
-
Table 20. Available I/O-Ports
