CC1010
SWRS047
Page 112 of 152
ISM
Frequency
[MHz]
Actual
frequency
[MHz]
Crystal
frequency
[MHz]
Low-side
/ high-
side
LO*
Reference
divider
REFDIV
[decimal]
Frequency
word
RX mode
FREQ
[decimal]
Frequency
word
RX mode
FREQ
[hex]
3.6864
3
11583488
B0C000
7.3728
6
11583488
B0C000
11.0592
9
11583488
B0C000
14.7456
12
11583488
B0C000
18.4320
15
11583488
B0C000
869.525
869.506000
22.1184
Low-side
18
11583488
B0C000
3.6864
2
7725056
75E000
7.3728
4
7725056
75E000
11.0592
6
7725056
75E000
14.7456
8
7725056
75E000
18.4320
10
7725056
75E000
869.85
869.860400
22.1184
High-side
12
7725056
75E000
3.6864
2
8126464
7C0000
7.3728
4
8126464
7C0000
11.0592
6
8126464
7C0000
14.7456
8
8126464
7C0000
18.4320
10
8126464
7C0000
915
915.018800
22.1184
High-side
12
8126464
7C0000
*Note: When using high-side LO injection the data received in RFBUF will be inverted.
Table 35. Recommended settings for ISM frequencies
