101 / 152 page

CC1010

SWRS047

Page 101 of 152

RFCON (0xC2) - RF Control Register

Bit

Name

R/W

Reset value

Description

7:5

Reserved, read as 0

MVIOL

Manchester code violation status of current bit in

bitmode or the aggregate-OR of the Manchester code

status of all bits in the current byte in bytemode. Only

valid when

MODEM0.DATA_FORMAT=01

(Manchester encoding)

3:1

MLIMIT(2:0)

R/W

011

Limit value used by the clock regeneration logic in

Manchester mode to determine whether the current

symbol constitutes a Manchester code violation. The

violation detection is determined by how balanced the

bit is by looking at the 14 samples. A perfect bit is 14

(all samples are correct). The limit can be set from 1 to

7 (001 – 111). 0 disable the violation detection

function.

BYTEMODE

R/W

Select bit or bytemode

0 : Bitmode is enabled. Data is transmitted and

received bit by bit through

RFBUF.0

1 : Bytemode is enabled. Data is transmitted and

received byte by byte through

RFBUF, with MSB first.

BYTEMODE is ignored if PDET.PEN = 1
