EM357-RTR Folha de dados(PDF) 21 Page - List of Unclassifed Manufacturers |
|
|
|||||||||||||||||||||||||||||
EM357-RTR Folha de dados(HTML) 21 Page - List of Unclassifed Manufacturers |
|
|
21 / 240 page  EM351 / EM357 2-8 120-035X-000D Preliminary Parameter Test Conditions Min. Typ. Max. Unit Linear RSSI range As defined by IEEE 802.15.4-2003 40 dB RSSI Range -90 -40 dBm Figure 2-3 shows the variation of receive sensitivity with temperature for boost mode and normal mode for a typical chip. Figure 2-3. Receive sensitivity vs temperature 2.7.2 Transmit Table 2-8 lists the key parameters of the integrated IEEE 802.15.4-2003 transmitter on the EM35x. Note: Transmit measurements were collected with Ember’s EM35x Ceramic Balun Reference Design (Version A0) at 2440 MHz. The Typical number indicates one standard deviation below the mean, measured at room temperature (25°C). The Min and Max numbers were measured over process corners at room temperature. In terms of impedance, this reference design presents a 3n3 inductor in parallel with a 1 00:50 Ω balun to the RF pins. |
|
