CC1150
SWRS037A
Page 56 of 60
0x38 (0xF8): PKTSTATUS – Current GDOx status
Bit
Field Name
Reset
R/W
Description
7:2
Reserved
R0
Defined on the transceiver version (
CC1101).
1
R0
Not Used.
0
GDO0
R
Current GDO0 value. Note: the reading gives the non-inverted
value irrespective what IOCFG0.GDO0_INV is programmed to.
It is not recommended to check for PLL lock by reading
PKTSTATUS[0]
with GDO0_CFG = 0x0A.
0x39 (0xF9): VCO_VC_DAC – Current setting from PLL calibration module
Bit
Field Name
Reset
R/W
Description
7:0
VCO_VC_DAC[7:0]
R
Status registers for test only.
0x3A (0xFA): TXBYTES – Underflow and number of bytes
Bit
Field Name
Reset
R/W
Description
7
TXFIFO_UNDERFLOW
R
6:0
NUM_TXBYTES
R
Number of bytes in TX FIFO.
