EM260
Page 13
120-0260-000M Rev 1.1
3.6
RF Electrical Characteristics
3.6.1
Receive
Table 7 lists the key parameters of the integrated IEEE 802.15.4 receiver on the EM260.
Note: Receive Measurements were collected with the Silicon Labs EM260 Ceramic Balun Reference Design at
2440MHz and using the EmberZNet software stack Version 3.0.1. The Typical number indicates one standard
deviation above the mean, measured at room temperature (25C). The Min and Max numbers are measured
over process corners at room temperature (25C).
Note: The adjacent channel rejection (ACR) measurements were performed by using an unfiltered, ideal IEEE
802.15.4 signal of continuous pseudo-random data as the interferer. For more information on ACR
measurement techniques, see document AN709, Adjacent Channel Rejection Measurements.
Table 7. Receive Characteristics
Parameter
Test Conditions
Min.
Typ.
Max.
Unit
Frequency range
2400
2500
MHz
Sensitivity (boost mode)
1% PER, 20byte packet defined by
IEEE 802.15.4
-
100
- 95
dBm
Sensitivity
1% PER, 20byte packet defined by
IEEE 802.15.4
- 99
- 94
dBm
High-side ACR
IEEE 802.15.4 signal at -82dBm
35
dB
Low-side ACR
IEEE 802.15.4 signal at - 82dBm
35
dB
2nd high-side ACR
IEEE 802.15.4 signal at - 82dBm
40
dB
2nd low-side ACR
IEEE 802.15.4 signal at - 82dBm
40
dB
Channel rejection for all other
channels
IEEE 802.15.4 signal at - 82dBm
40
dB
802.11g rejection centered at +
12MHz or - 13MHz
IEEE 802.15.4 signal at - 82dBm
35
dB
Maximum input signal level for
correct operation (low gain)
0
dBm
Image suppression
30
dB
Co-channel rejection
IEEE 802.15.4 signal at - 82dBm
- 6
dBc
Relative frequency error
(2 x 40 ppm required by IEEE
802.15.4)
-
120
+
120
ppm
Relative timing error
(2 x 40 ppm required by IEEE
802.15.4)
-
120
+
120
ppm
Linear RSSI range
40
dB
RSSI Range
- 90
- 30
dB
