AT89C5132-ROTIL Folha de dados(PDF) 1 Page - ATMEL Corporation |
|
|
|||||||||||||||||||||||||||||
AT89C5132-ROTIL Folha de dados(HTML) 1 Page - ATMEL Corporation |
|
|
1 / 181 page  Features • Programmable Audio Output for Interfacing with Common Audio DAC – PCM Format Compatible –I2S Format Compatible • 8-bit MCU C51 Core-based (F MAX = 20 MHz) • 2304 Bytes of Internal RAM • 64K Bytes of Code Memory – AT89C5132: Flash (100K Write/Erase Cycles) • 4K Bytes of Boot Flash Memory (AT89C5132) – ISP: Download from USB (standard) or UART (option) • USB Rev 1.1 Device Controller – “Full Speed” Data Transmission • Built-in PLL • MultiMedia Card® Interface Compatibility • Atmel DataFlash® SPI Interface Compatibility • IDE/ATAPI Interface • 2 Channels 10-bit ADC, 8 kHz (8 True Bits) – Battery Voltage Monitoring – Voice Recording Controlled by Software • Up to 44 Bits of General-purpose I/Os – 4-bit Interrupt Keyboard Port for a 4 x n Matrix – SmartMedia® Software Interface • Two Standard 16-bit Timers/Counters • Hardware Watchdog Timer • Standard Full Duplex UART with Baud Rate Generator • Two Wire Master and Slave Modes Controller • SPI Master and Slave Modes Controller • Power Management – Power-on Reset – Software Programmable MCU Clock – Idle Mode, Power-down Mode • Operating Conditions –3V, ±10%, 25 mA Typical Operating at 25°C – Temperature Range: -40 °C to +85°C • Packages – TQFP80, PLCC84 (Development Board Only) –Dice 1. Description The AT89C5132 is a mass storage device controlling data exchange between various Flash modules, HDD and CD-ROM. The AT89C5132 includes 64K Bytes of Flash memory and allows In-System Program- ming through an embedded 4K Bytes of Boot Flash Memory. The AT89C5132 include 2304 Bytes of RAM memory. The AT89C5132 provides all the necessary features for man-machine interface including, timers, keyboard port, serial or parallel interface (USB, SPI, IDE), ADC input, I 2S output, and all external memory interface (NAND or NOR Flash, SmartMe- dia, MultiMedia, DataFlash cards). 2. Typical Applications • Flash Recorder/Writer • PDA, Camera, Mobile Phone • PC Add-on USB Microcontroller with 64K Bytes Flash Memory AT89C5132 Preliminary 4173D–USB–02/06 |
