Data Sheet
ADL8113
analog.com
Rev. 0 | 5 of 37
SPECIFICATIONS
200MH
z TO 6GHz FREQUENCY RANGE
VDD1 = +5V, IDQ = 110mA, VSS2 = −3.3V, VDD2 = +3.3V, and TCASE = 25°C, unless otherwise noted.
Table 2. 200MHz to 6GHz Frequency Range Specifications
Parameter
Test Conditions/Comments
Min
Typ
Max
Unit
OVERALL FUNCTION
Frequency Range
0.200
6
GHz
INTERNAL AMPLIFIER MODE
Small Signal Gain
12.0
14.0
dB
Gain Flatness
±0.25
dB
S11
15
dB
S22
17
dB
OP1dB
18.5
20.5
dBm
OIP3
Measurement taken at POUT per tone =
5dBm
35.5
dBm
OIP2
Measurement taken at POUT per tone =
5dBm
41.7
dBm
Noise Figure
3.8
dB
INTERNAL BYPASS SWITCH MODE
Insertion Loss
2.2
dB
S11
21
dB
S22
23
dB
IIP3
Measurement taken at PIN per tone =
14dBm
50
dBm
IP0.1dB
27.5
dBm
IP1dB
28
dBm
EXTERNAL BYPASS A MODE
Insertion Loss
RFIN to OUT_A or IN_A to RFOUT
1.2
dB
S11
Looking into RFIN
23.5
dB
Looking into IN_A
23.5
dB
Looking into IN_B
1.5
dB
S22
Looking into RFOUT
25
dB
Looking into OUT_A
25
dB
Looking into OUT_B
1.5
dB
IP0.1dB
Looking into RFIN to OUT_A or IN_A to
RFOUT
27.5
dBm
IP1dB
Looking into RFIN to OUT_A or IN_A to
RFOUT
28
dBm
IIP3
Looking into RFIN to OUT_A or IN_A to
RFOUT; measurement taken at PIN per
tone = 14dBm
50
dBm
EXTERNAL BYPASS B MODE
Insertion Loss
RFIN to OUT_B or IN_B to RFOUT
1.2
dB
S11
Looking into RFIN
23.5
dB
Looking into IN_A
1.5
dB
Looking into IN_B
23.5
dB
S22
Looking into RFOUT
25
dB
Looking into OUT_A
1.5
dB
Looking into OUT_B
25
dB
IP0.1dB
RFIN to OUT_B or IN_B to RFOUT
27.5
dBm
IP1dB
RFIN to OUT_B or IN_B to RFOUT
28
dBm
