THEORY OF OPERATION

MASTER CLOCK

The SSM2537 requires a clock present at the PCLK input pin to

operate. This clock must be fully synchronous with the incoming

digital audio on the serial interface. Clock frequencies must fall

into one of these ranges: 1.84 MHz to 3.23 MHz or 3.68 MHz to

6.46 MHz.

POWER SUPPLIES

The SSM2537 requires two power supplies: PVDD and VDD.

PVDD

PVDD supplies power to the full-bridge power stage of the

MOSFET and its associated drive, control, and protection

circuitry. It also supplies power to the digital-to-analog

converter (DAC) and to the Class-D PDM modulator. PVDD

can operate from 2.5 V to 5.5 V and must be present to obtain

audio output. Lowering the supply voltage of PVDD results in

lower maximum output power and, therefore, lower power

consumption.

VDD

VDD provides power to the digital logic circuitry. VDD can

operate from 1.65 V to 1.95 V and must be present to obtain

audio output. Lowering the supply voltage of VDD results in

lower power consumption but does not affect audio performance.

POWER CONTROL

On device power-up, PVDD must first be applied to the device,

which latches in the designated GAIN_FS pin functionality.

The SSM2537 contains a smart power-down feature. When

enabled, the smart power-down feature looks at the incoming

digital audio and, if it receives the PDM stop condition of at

least 129 repeated 0xAC bytes (1024 clock cycles), it places

the SSM2537 in standby mode. In standby mode, PCLK can

be removed, resulting in a full power-down state. This state

is the lowest power condition possible. When PCLK is turned

on again and a single non-stop condition input is received, the

SSM2537 leaves the full power-down state and resumes normal

operation under the default setting as indicated by the

GAIN_FS pin state.

POWER-ON RESET/VOLTAGE SUPERVISOR

The SSM2537 includes an internal power-on reset and voltage

supervisor circuit. This circuit provides an internal reset to

circuitry when PVDD or VDD is substantially below the

nominal operating threshold. This simplifies supply sequencing

during initial power-on.

The circuit also monitors the power supplies to the IC. If the

supply voltages fall below the nominal operating threshold, this

circuit stops the output and issues a reset. This is done to ensure

that no damage occurs due to low voltage operation and that no

pops can occur under nearly any power removal condition.

SYSTEM GAIN/INPUT FREQUENCY

The GAIN_FS pin is used to set the internal gain and filtering

configuration for different sample rates of the SSM2537. This

pin can be set to one of four states by connecting the pin either

to PVDD or to PGND with or without a 47 kΩ resistor (see

Table 7). The internal gain and filtering can also be set via PDM

pattern control, allowing these settings to be modified during

operation (see the PDM Pattern Control section).

The SSM2537 has an internal analog gain control such that

when GAIN_FS is tied to PGND or PVDD via a 47 kΩ resistor

(5 V gain setting), a −6.02 dBFS PDM input signal results in

an amplifier output voltage of 5 V peak. This setting should

produce optimal noise performance when PVDD is 5 V.

When the GAIN_FS pin is tied to PVDD or pulled directly to

PGND, the gain is adjusted so that a −6.02 dBFS PDM input

signal results in an amplifier output voltage of 3.6 V peak. This

setting should produce optimal noise performance when PVDD

is 3.6 V.

in each of these cases. Selection of the sample rate is also set via

the GAIN_FS pin (see Table 7).

lower power consumption, its use is recommended. The 128

performance is limited by the source modulator.

Table 7. GAIN_FS Function Descriptions

Device Setting

GAIN_FS Pin Configuration

f

Pull up to PVDD with a 47 kΩ

resistor

f

Pull down to PGND with a 47 kΩ

resistor

f

Pull up to PVDD

f

Pull down to PGND
