P9221-R3 Datasheet

© 2017 Integrated Device Technology, Inc.

11

October 20, 2017

Symbol

Description

Conditions

Min

Typical

Max

Units

tHIGH

Clock High Period

0.6

µs

tSU:STA

Set-up Time for Repeated

START Condition

0.6

µs

tBUF

Bus Free Time Between

STOP and START

Condition

1.3

µs

CB

Capacitive Load for SCL

and SDA

150

pF

CI

SCL and SDA Input

Capacitance

5

pF

Thermal Shutdown

TSD

Thermal Shutdown

Rising[b]

140

°C

Falling

120

°C

[a] Do not externally load. For internal biasing only.

[b] If the die temperature exceeds 130°C, the Thermal_SHTDN_Status flag is set to “1”and an End Power Transfer (EPT) packet is sent (see Table 14).
