background image
P9221-R3 Datasheet
© 2017 Integrated Device Technology, Inc.
36
October 20, 2017
Table 30. Outgoing User Data Registers
Address and Bit
Register or Bit Field Name
R/W
Default
Function and Description
0089HEX
Outgoing_User_Data_0
RW
00HEX
The application processor writes into this register the data it
will be sending to the P9242-R3.
008AHEX
Outgoing_User_Data_1
RW
00HEX
The application processor writes into this register the data it
will be sending to the P9242-R3.
008BHEX
Outgoing_User_Data_2
RW
00HEX
The application processor writes into this register the data it
will be sending to the P9242-R3.
008CHEX
Outgoing_User_Data_3
RW
00HEX
The application processor writes into this register the data it
will be sending to the P9242-R3.
008DHEX
Outgoing_User_Data_4
RW
00HEX
The application processor writes into this register the data it
will be sending to the P9242-R3.
008EHEX
Outgoing_User_Data_5
RW
00HEX
The application processor writes into this register the data it
will be sending to the P9242-R3.
008FHEX
Outgoing_User_Data_6
RW
00HEX
The application processor writes into this register the data it
will be sending to the P9242-R3.
0090HEX
Outgoing_User_Data_7
RW
00HEX
The application processor writes into this register the data it
will be sending to the P9242-R3.
Table 31. WPC Power Transfer Phase Indicator Register
Address and Bits
Register Field Name
R/W
Default
Function and Description
014AHEX
System_State
R
00HEX
0DEC = Selection Phase
1DEC = Identification Phase
2DEC = Configuration Phase
3DEC = Post-Configuration Phase
4DEC = Negotiation Phase
5DEC = Power Transfer Phase
6DEC = Reserved
7DEC = Renegotiation Transfer Phase
8DEC = Error Phase
