P9221-R3 Datasheet
© 2017 Integrated Device Technology, Inc.
38
October 20, 2017
13.2 Recommended Coils
The following coils are recommended with the P9221-R3 receiver for 15W applications for optimum performance. The recommended vendor
coils have been tested and verified as shown in Table 32.
Table 32. Recommended Coil Manufacturers
Output Power
Vendor
Part number
Inductance at 100kHz
ACR at 20°C
Series Resonant Capacitance
15W
AMOTECH
ASC-504060E00-S00
8.2µH
220mΩ
400nF
15W
TDK
WR424245-13K2-G
11.2µH
170mΩ
300nF
15W
SUNLORD
SWA50R40H06C02B
8.4µH
150mΩ
400nF
15W
WURTH
760308102207
8.0µH
80mΩ
400nF
