P9415-R Datasheet

May 4, 2021

12. Package Outline Drawings

The package outline drawings are located at the end of this document and are accessible from the Renesas website. The package information

is the most current data available and is subject to change without revision of this document.

13. Marking Diagram

IDT

P9415

YYWW**

$-R

NNCCRR

Line 1. is the manufacturer.

Line 2. is the truncated part number.

Line 3. “YYWW” is the last 2 digits of the year and week that the part was assembled.

“**” denotes sequential lot number.

Line 4. “$” denotes assembly mark code. ” “R” is part of the device part number.

Line 5. “NN” is the wafer number; “CC” is the column or X- coordinate of the wafer; “RR” is the row or Y-

coordinate of the wafer.

14. Ordering Information

Orderable Part Number

Package

MSL Rating

Shipping

Packaging

Ambient

Temperature

Firmware[a]

P9415-RAWQI8

AWQ53 WLCSP-53 2.82 × 4.22 ×

0.50 mm with 0.4mm pitch

MSL 1

Tape and Reel

-40° to +85°C

Blank

15. Revision History

Revision Date

Description of Change

May 4, 2021

Updated “GP1/Q Main Pin and GP3/Q Offset Pin”

September 4, 2020

Updated the VMLDO specifications in Table 4

Updated the address and bit field in Table 30

September 1, 2020

Initial release.
