background image
P9415-R Datasheet
© 2021 Renesas Electronics Corporation
58
May 4, 2021
Table 58. Read Data Register for WPC 1.3 (0x196)
Address
and Bit
Register Field Name
R/W
Default
Value
Function and Description
0x196[15:0]
ccRdSize
R
0
Length of the raw data received from Tx
Procedure of WPC1.3 bi-di communication
1. Clear interrupt.
2. AP writes raw data to Write Data Register (0x1A4).
3. AP writes type and data length to Write Data Type and Length Register (0x1A0, 2 bytes).
4. AP writes command 0x02 to system command register (0x4F, 1 byte) to send the data out.
5. AP waits for interrupt (ADTRCVD).
6. AP reads received data length from Read Data Register (0x196, 2 bytes).
7. AP reads received data from Read Data Register (0x3A4).
