P9415-R Datasheet

May 4, 2021

Table 46. Vrect Register in Tx Mode (0x72)

Address

and Bit

R/W

Default

Value

Function and Description

0x72 [15:0]

TxVrect

Vrect voltage in Tx mode, value in mV.

Table 47. End Power Transfer Reason Register (0x74)

Address

and Bit

R/W

Default

Value

Function and Description

0x75 [7]

EPT_POCP

1 = Indicates over current protect during digital ping

0 = No such error

0x75 [6]

EPT_OTP

1 = Over current error

0 = No such error

0x75 [5]

EPT_FOD

1 = FOD error

0 = No such error

0x75 [4]

EPT_LVP

1 = Vrect is less than low voltage protection threshold

0 = No such error

0x75 [3]

EPT_OVP

1 = Over voltage error

0 = No such error

0x75 [2]

EPT_OCP

1 = Over current error

0 = No such error

0x75 [1]

Reserved

0x75 [0]

EPT_CEP_TIMEOUT

1 = CEP timeout

0 = No such error

0x74 [7]

EPT_TIMEOUT

1 = Watch dog timeout

0 = No such error

0x74 [6:1]

Reserved

0x74 [0]

EPT_CMD

1 = End power transfer packet has been received

0 = No such error
