36 / 105 page

T89C5115

4128A–8051–04/02

Figure 15. Reading Procedure

Flash Protection from Parallel

Programming

The three lock bits in Hardware Security Byte (see "In-System Programming" section)

are programmed according to Table 22 provide different level of protection for the on-

chip code and data located in FM0 and FM1.

The only way to write this bits are the parallel mode. They are set by default to level 3.

Table 22. Program Lock bit

Program Lock bits

U: unprogrammed

P: programmed

WARNING: Security level 2 and 3 should only be programmed after Flash and Core

verification.

Preventing Flash Corruption

See paragraph in the "Power Management" section, page 17.

Flash Spaces Reading

Flash Spaces Mapping

FCON= 00000xx0b

Data Read

DPTR= Address

ACC= 0

Exec:MOVCA,@A+DPTR

Clear Mode

FCON = 00h

Program Lock Bits

Protection Description

Security

level

LB0

LB1

LB2

No program lock features enabled. MOVC instruction executed from

external program memory returns non encrypted data.

Parallel programming of the Flash is disabled.

Same as 2, also verify through parallel programming interface is

disabled.
