T89C5115
4128A–8051–04/02
Registers
PCON (S:87h)
Table 14. PCON Register
Power Configuration Register
Reset Value = XXXX 0000b
76
54
32
1
0
––
––
GF1
GF0
PD
IDL
Bit
Number
Bit
Mnemonic
Description
7-4
–
Reserved
The value read from these bits is indeterminate. Do not set these bits.
3GF1
General-purpose flag 1
One use is to indicate whether an interrupt occurred during normal operation or
during Idle mode.
2GF0
General-purpose flag 0
One use is to indicate whether an interrupt occurred during normal operation or
during Idle mode.
1PD
Power-down Mode bit
Cleared by hardware when an interrupt or reset occurs.
Set to activate the Power-down mode.
If IDL and PD are both set, PD takes precedence.
0IDL
Idle Mode bit
Cleared by hardware when an interrupt or reset occurs.
Set to activate the Idle mode.
If IDL and PD are both set, PD takes precedence.
