SPEAr320

Architecture overview

Doc ID 16755 Rev 5

21/73

●

Slave bulk transfer mode

●

Ignores CBUS addresses (predessor to I2C that used to share the I2C bus)

●

Transmit and receive buffers

●

Interrupt or polled-mode operation

●

Handles bit and byte waiting at all bus speeds

●

Digital filter for the received SDA and SCL lines

●

Handles component parameters for configurable software driver support

●

Supports APB data bus widths of 8, 16 and 32 bits.

3.18

UARTs

The SPEAr320 has 3 UARTs with different capabilities.

3.18.1

UART0

Main features:

●

Separate 16 x 8 (16 locations deep x 8-bit wide) transmit and 16 x 12 receive FIFOs to

reduce CPU interrupts

●

Speed up to 3 Mbps

●

Hardware and/or software flow control

●

Modem interface signals

3.18.2

UART1

Main features:

●

Separate 16 x 8 (16 location deep x 8-bit wide) transmit and 16x12 receive FIFOs to

reduce CPU interrupts

●

Speed up to 7 Mbps

●

Hardware flow control (in Small Printers and Automation Expansion modes only) and/or

software flow control

3.18.3

UART2

Main features:

●

Separate 16x8 (16 location deep x 8-bit wide) transmit and 16x12 receive FIFOs to

reduce CPU interrupts

●

Speed up to 7 Mbps

●

Software flow control

3.19

JPEG CODEC

SPEAr320 provides a JPEG CODEC with header processing (JPGC), able to decode (or

encode) image data contained in the SPEAr320 RAM, from the JPEG (or MCU) format to

the MCU (or JPEG) format.
