SSM2604

Rev. 0 | Page 11 of 28

THEORY OF OPERATION

DIGITAL CORE

Inside the SSM2604 digital core is a central clock source, called

the master clock (MCLK), that produces a reference clock for

all internal audio data processing and synchronization. When

using an external clock source to drive the MCLK pin, great

care should be taken to select a clock source with less than 50 ps

of jitter. Without careful generation of the MCLK signal, the

digital audio quality likely suffers.

To enable the SSM2604 to generate the central reference clock

in a system, connect a crystal oscillator between the MCLK/XTI

input pin and the XTO output pin.

To allow an external device to generate the central reference

clock, apply the external clock signal directly through the MCLK/

XTI input pin. In this configuration, the oscillator circuit of the

SSM2604 can be powered down by using the OSC bit (Register

R6, Bit D5) to reduce power consumption.

To accommodate applications with very high frequency master

clocks, the internal core reference clock of the SSM2604 can be

set to either MCLK or MCLK divided by 2. This is enabled by

adjusting the setting of the CLKDIV2 bit (Register R8, Bit D6).

Complementary to this feature, the CLKOUT pin can also drive

external clock sources with either the core clock signal or the

core clock divided by 2 by enabling the CLKODIV2 bit

(Register R8, Bit D7).

ADC AND DAC

The SSM2604 contains a pair of oversampling Σ-Δ ADCs.

The maximum ADC full-scale input level is 1.0 V rms when

AVDD = 3.3 V. If the input signal to the ADC exceeds this

level, data overloading occurs and causes audible distortion.

The ADC accepts analog audio input from the stereo line

inputs. The digital data from the ADC output, once converted,

is processed using the ADC filters.

Complementary to the ADC channels, the SSM2604 contains a

pair of oversampling Σ-Δ DACs that convert the digital audio

data from the internal DAC filters into an analog audio signal.

The DAC output can also be muted by setting the DACMU bit

(Register R5, Bit D3) in the control register.

ADC HIGH-PASS AND DAC DE-EMPHASIS FILTERS

The ADC and DAC employ separate digital filters that perform

24-bit signal processing. The digital filters are used for both

record and playback modes and are optimized for each individ-

ual sampling rate used.

For recording mode operations, the unprocessed data from the

ADC enters the ADC filters and is converted to the appropriate

sampling frequency, and then is output to the digital audio

interface.

For playback mode operations, the DAC filters convert the digital

audio interface data to oversampled data, using a sampling rate

selected by the user. The oversampled data is processed by the

DAC and then is sent to the analog output mixer by enabling

the DACSEL (Register R4, Bit D4).

Users have the option of setting up the device so that any dc

offset in the input source signal is automatically detected and

removed. To accomplish this, enable the digital high-pass filter

(see Table 2 for characteristics) contained in the ADC digital

filters by using the ADCHPF bit (Register R5, Bit D0).

In addition, users can implement digital de-emphasis by using

the DEEMPH bits (Register R5, Bit D1 and Bit D2).
