A22NE-P

• Do not wire anything to the release holes.

• Do not tilt or twist a flat-blade screwdriver while it is inserted into a

release hole on the terminal block. The terminal block may be

damaged.

• Insert a flat-blade screwdriver into the release holes at an angle.

The terminal block may be damaged if you insert the screwdriver

straight in.

• Do not allow the flat-blade screwdriver to fall out while it is inserted

into a release hole.

• Do not bend a wire past its natural bending radius or pull on it with

excessive force.

Doing so may cause the wire disconnection.

• Do not insert more than one wire into each terminal insertion hole.

• Do not mount A22N-P or A22NE-P Push-In Plus terminal switch

blocks on A22N screw terminal blocks. Doing so may result in

unsatisfactory performance.

Wiring

1. Connecting Wires to the Push-In Plus Terminal Block

Part Names of the Terminal Block

Connecting Wires with Ferrules and Solid Wires

• Insert the solid wire or ferrule straight into the terminal block until

the end strikes the terminal block. The angle should be

approximately 6

°.

• If a wire is difficult to connect because it is too thin, use a flat-blade

screwdriver in the same way as when connecting stranded wires.

Precautions for Correct Use

Release hole

Terminal (insertion) hole

Ferrule or solid wire

Approx. 6˚

The wiring for the Lighting Unit and Switch Block (2 contacts) are the

same as for the Switch Block (1 contact) shown in the above illustra-

tion.
