A22NE-P
24
Dimensions
(Unit: mm)
Non-lighted Models
Note: Unless otherwise specified, a tolerance of ±0.8mm applies to all dimensions.
Dimensions when a two-contact Switch Block is attached
A22NE-MP-P
@@2-N
A22NE-S-P
@@2-N
A22NE-M-P
@@2-N
A22NE-L-P
@@2-N
Lighted Model
A22NE-M-P
@@2-@
1.8
5.9
0.5
32
39.5
40 dia.
42.5
Pull-reset (40-dia.)
1.8
5.9
0.5
32
39.5
30 dia.
42.5
Small Turn-reset (30-dia.)
1.8
5.9
0.5
32
39.5
40 dia.
42.5
Note: The dimensions the same even if the Operation Unit is replaced
with the A22NE-MR
@-N or the A22NE-MR@-N-RD.
Medium Turn-reset (40-dia.)
60 dia.
1.8
5.9
0.5
32
39.5
42.5
Large Turn-reset (60-dia.)
40 dia.
1.8
5.9
0.5
32
39.5
42.5
Medium Turn-reset (40-dia.)
40 dia.
0.5
1.8
5.9
55
44
32
