A22E

Specifications

Certified Standard Ratings

• UL, cUL (File No. E41515)

6 A at 220 VAC, 10 A at 110 VAC

• TÜV (EN60947-5-1) (Low Voltage Directive)

3 A at 220 VAC

• CCC (GB14048.5)

3 A at 240 VAC, 1.5 A at 24 VDC

Certified Standards

Note: Only models with NC contacts have a direct opening mechanism.

*1. UL-certification for CSA C22.2 No. 14 has been obtained.

Certification has been obtained for individual Switch Blocks and

Lighting Units.

*2. Some models have been certified.

Ratings

Contacts (Standard Load)

Note: 1. Rated current values are determined according to the

testing conditions. The above ratings were obtained by

conducting tests under the following conditions.

(1) Ambient temperature: 20

°±2°C

(2) Ambient humidity: 65

±5%

(3) Operating frequency: 20 operations/minute

2. Minimum applicable load: 10 mA at 5 VDC

LED Lamp

Voltage-reduction lighting

Characteristics

*1. With no icing or condensation.

*2. The degree of protection from the front of the panel.

*3. The degree of protection is IP65 even with an integrated control box, but the system is not oil resistant.

Certification

body

Standards

File No.

UL508, C22.2 No.14

E41515

TÜV SÜD

EN60947-5-1

(Certified direct opening),

EN60947-5-5

Consult your OMRON

representative for details.

CQC (CCC)

GB14048.5

2003010303070635

KOSHA

EN60947-5-1

Consult your OMRON

representative for details.

Rated carry

current (A)

Rated

voltage (V)

Rated current (A)

AC15

(Inductive

load)

AC12

(Resistive

load)

DC13

(Inductive

load)

DC12

(Resistive

load)

24 VAC

---

110 VAC

220 VAC

380 VAC

440 VAC

24 VDC

---

1.5

110 VDC

0.5

220 VDC

0.2

0.6

380 VDC

0.1

0.2

Rated voltage

Operating voltage

Current value

6 VAC/VDC

6 VAC/VDC ± 5%

Approx. 8 mA

12 VAC/VDC

12 VAC/VDC ± 5%

24 VAC/VDC

24 VAC/VDC ± 5%

Rated voltage Operating voltage Rated current

Applicable lamp

(BA9S/Base: 13)

110 VAC

100 VAC

(95 to 115 V)

Approx. 8 mA

LED lamp

A22-24A

220 VAC

200 VAC

(190 to 230 V)

Type

Turn-reset

Pull-reset

Item

Non-lighted model

Lighted model

Non-lighted model

Allowable operating

frequency

Mechanical

operations/minute (One operation consists of set and reset operations.)

Electrical

operations/minute (One operation consists of set and reset operations.)

Insulation resistance

100 M

Ω min. (at 500 VDC)

Contact resistance

100 m

Ω max. (initial value)

Dielectric strength

Between terminals of same polarity

2,500 VAC, 50/60 Hz for 1 min.

Between each terminal and ground

2,500 VAC, 50/60 Hz for 1 min.

Vibration resistance

10 to 55 Hz, 1.5-mm double amplitude (contact separation within 1 ms)

Shock resistance

Destruction

1000 m/s2

Malfunction

250 m/s2 max. (contact separation within 1 ms)

Durability

Mechanical

300,000 operations min. (One operation consists of set and reset operations.)

Electrical

300,000 operations min. (One operation consists of set and reset operations.)

Ambient operating temperature

-20 to +70°C

-20 to +55°C

-20 to +70°C

Ambient operating humidity

35 to 85% RH

Ambient storage temperature

-40 to +70°C

Degree of protection

IP65 (oil-resistant)

*2 *3

IP65

IP65 (oil-resistant)

*2 *3

Electric shock protection class

Class II

PTI (tracking characteristic)

175

Degree of contamination

3 (EN60947-5-1)

Minimum direct opening stroke

11 mm

Minimum direct opening force

45 N

Conditional short-circuit current

100 A (EN 60947-5-1)

Weight (for a 40-dia. head 1NC/1NO Operation Unit)

Approx. 65 g

Approx. 80 g

Approx. 100 g
