CY244/45ZXC
Document #: 38-07748 Rev. **
Page 4 of 9
Absolute Maximum Conditions
Parameter
Description
Condition
Min.
Max.
Unit
VDD/AVDD/VDDL Core Supply Voltage
–0.5
4.6
V
VIN
Input Voltage
Relative to VSS
–0.5
VDD + 0.5
VDC
TS
Temperature, Storage
Non-Functional
–65
+125
°C
ESDHBM
ESD Protection (Human Body Model)
MIL-STD-883, Method 3015
2000
–
Volts
UL-94
Flammability Rating
V-0 @1/8 in.
–
10
ppm
MSL
Moisture Sensitivity Level
16 and 20 pin TSSOP
1
Pullable Crystal Specifications[2, 4]
Parameter
Description
Comments
Min.
Typ.
Max.
Unit
FNOM
10 to 30 MHz Crystal AT-Cut
Parallel resonance, Fundamental mode
See Note 4
CLNOM
Nominal load capacitance
CLNOM =14 pF (0 ppm)
13.5
14
14.5
pF
R1
Equivalent series resistance (ESR)
Fundamental mode (CL = Series)
–
–
25
Ω
DL
Crystal drive level
No external series resistor assumed
–
–
500
µW
C0[3]
Crystal shunt capacitance
–
–
7
pF
C1[3]
Crystal motional capacitance
14.4
18
21.6
fF
F3SEPHI[4]
Third overtone separation from 3*FNOM Mechanical Third (High side of 3*FNOM)
380
–
–
ppm
F3SEPLO[4] Third overtone separation from 3*FNOM Mechanical Third (Low side of 3*FNOM)
–
–
–170
ppm
C0/C1
Ratio of shunt to motional capacitance
–
–
250
Recommended Operating Conditions
Parameter
Description
Min.
Typ.
Max.
Unit
VDD/AVDD/VDDL Operating Voltage
3.0
3.3
3.6
V
TA
Ambient Temperature
0
–
70
°C
CLOAD
Maximum Load Capacitance
–
–
15
pF
tPU
Power-up time for all VDDs reach minimum specified voltage (power
ramps must be monotonic)
0.05
–
500
ms
DC Parameters
Parameter
Description
Conditions
Min.
Typ.
Max.
Unit
IOH[5]
Output High Current
VOH = VDD – 0.5, VDD = 3.3V
–
12
–
mA
IOL[5]
Output Low Current
VOL = 0.5, VDD = 3.3V
–
12
–
mA
IIH
Input High Current
VIH = VDD, excluding Vin, Xin
–
5
10
µA
IIL
Input Low Current
VIL = 0V, excluding Vin, Xin
–
5
10
µA
VIH
Input High Voltage
FS0/1/2 OE input CMOS levels
0.7xAVDD
––
V
VIL
Input Low Voltage
FS0/1/2 OE input CMOS levels
–
–
0.3xAVDD
V
VVCXO
VIN Input Range
0
–
AVDD
V
CIN
Input Capacitance
FS0/1/2 and OE Pins only
–
–
7
pF
IVDD
Supply Current
VDD/AVDD/VDDL Current
–
85
–
mA
CINXIN
Input Capacitance at XIN
VCXO Disabled External Reference
–
15
–
pF
Crystal Load
Crystal Load Capacitance
VCXO Disabled Fixed Freq. Crystal
–
10
–
pF
Notes:
2. Device operates to the following specs, which are guaranteed by design.
3. Increased tolerance available from pull range less than ±120 ppm.
4. ECX-5953 Series crystal orderable from Ecliptek Corporation. Please refer to the CY22388/89/91 data sheet for compatibility with most SMD type crystals.
5. Parameters are guaranteed by design and characterization. Not 100% tested in production. All parameters specified with fully loaded outputs.
