2025-2026 Microchip Technology Inc. and its subsidiaries
DS20007043B-page 5
MIC24054
TEMPERATURE SPECIFICATIONS
Parameters
Sym.
Min.
Typ.
Max.
Units
Conditions
Temperature Ranges
Maximum Junction Temperature
TJ(MAX)
—
—
+150
°C
—
Junction Temperature Range
TJ
–40
—
+125
°C
—
Storage Temperature Range
TS
–65
—
+150
°C
—
Lead Temperature
TLEAD
—
—
+260
°C
Soldering, 10 sec.
Package Thermal Resistance
Thermal Resistance, VQFN 28-Ld
θJA
—
28
—
°C/W —
