MIC24054
DS20007043B-page 26
2025-2026 Microchip Technology Inc. and its subsidiaries
FIGURE 7-2:
Schematic of MIC24054 Evaluation Board (J11, R13, R15 are for Testing Purposes)
Optimized for Smaller Footprint.
TABLE 7-1:
BILL OF MATERIALS
Item
Part Number
Manufacturer
Description
Qty.
C1
Open
—
—
—
C2, C3
12103C475KAT2A
AVX
4.7 µF Ceramic Capacitor, X7R, Size
1210, 25V
2
GRM32DR71E475KA61K
Murata
C3225X7R1E475K
TDK
C13, C15
Open
—
—
—
C4, C5
12106D107MAT2A
AVX
100 µF Ceramic Capacitor, X5R, Size
1210, 6.3V
2
GRM32ER60J107ME20L
Murata
C3225X5R0J107M
TDK
