E3X
E3X
30
Number of Turns of Sensitivity
Adjuster and Sensing Distance (Typical)
E3X-H/E32-D11L
Color Sensing (Typical)
Green Light Source E3X-VG
j /E32-D11L
Sensitivity adjuster
Color paper
(2.5 x 2.5 cm)
Munsell chroma (MC)
Number of turns
E3X-A
j
E3X-F
j
10
°
5 mm
White CM484
Yellow CM124
Amber CM 78
Yellow green CM157
Orange CM 85
Aqua CM263
Red CM 6
Purple CM379
Magenta CM431
Blue CM336
Green CM241
Black CM489
Sensing Object: White Paper of 5 x 5 cm
The following graph shows the relationship between colors and the
number of turns of the sensitivity adjustor when the E32-D11L is in
operation with the sensing distance adjusted to 5 mm.
E3X-A, -F/E32-D11L
Sensing Object: White Paper of 10 x 10 cm
with E3X-A and 5 x 5 cm with E3X-F
Sensitivity adjuster
