KSZ9567R

DS00002329D-page 14

 2017-2019 Microchip Technology Inc.

LED Pins

Port 1

LED Indicator 0

LED1_0

IPU/O8

Port 1 LED Indicator 0.

Active low output sinks current to light an external LED.

Port 1

LED Indicator 1

LED1_1

IPU/O8

Port 1 LED Indicator 1.

Active low output sinks current to light an external LED.

Note:

This pin also provides configuration strap func-

tions during hardware/software resets. Refer to

Section 3.2.1, "Configuration Straps" for addi-

tional information.

Port 2

LED Indicator 0

LED2_0

IPU/O8

Port 2 LED Indicator 0.

Active low output sinks current to light an external LED.

Note:

This pin also provides configuration strap func-

tions during hardware/software resets. Refer to

Section 3.2.1, "Configuration Straps" for addi-

tional information.

Port 2

LED Indicator 1

LED2_1

IPU/O8

Port 2 LED Indicator 1.

Active low output sinks current to light an external LED.

Note:

This pin also provides configuration strap func-

tions during hardware/software resets. Refer to

Section 3.2.1, "Configuration Straps" for addi-

tional information.

Port 3

LED Indicator 0

LED3_0

IPU/O8

Port 3 LED Indicator 0.

Active low output sinks current to light an external LED.

Port 3

LED Indicator 1

LED3_1

IPU/O8

Port 3 LED Indicator 1.

Active low output sinks current to light an external LED.

Note:

This pin also provides configuration strap func-

tions during hardware/software resets. Refer to

Section 3.2.1, "Configuration Straps" for addi-

tional information.

Port 4

LED Indicator 0

LED4_0

IPU/O8

Port 4 LED Indicator 0.

Active low output sinks current to light an external LED.

Note:

This pin also provides configuration strap func-

tions during hardware/software resets. Refer to

Section 3.2.1, "Configuration Straps" for addi-

tional information.

Port 4

LED Indicator 1

LED4_1

IPU/O8

Port 4 LED Indicator 1.

Active low output sinks current to light an external LED.

Note:

This pin also provides configuration strap func-

tions during hardware/software resets. Refer to

Section 3.2.1, "Configuration Straps" for addi-

tional information.

Port 5

LED Indicator 0

LED5_0

IPU/O8

Port 5 LED Indicator 0.

Active low output sinks current to light an external LED.

Port 5

LED Indicator 1

LED5_1

IPU/O8

Port 5 LED Indicator 1.

Active low output sinks current to light an external LED.

Note:

This pin also provides configuration strap func-

tions during hardware/software resets. Refer to

Section 3.2.1, "Configuration Straps" for addi-

tional information.

TABLE 3-2:

PIN DESCRIPTIONS (CONTINUED)

NAME

SYMBOL

BUFFER

TYPE

DESCRIPTION
