RISC Computing Platforms

Features

ƒ

MediaTek Genio 1200 4 cores A78 & 4 cores A55

ƒ

Onboard LPDDR4 8GB, 4000MT/s memory

ƒ

HDMI 4k60fps, 1 x Dual Channel 24 bit LVDS

ƒ

1 x 4-wire RS-232/422/485, 2 x USB3.2 Gen1 By 1, 2 x USB2.0,

1 x Micro SD, 1 x Mic. in / Line out

ƒ

1 x M.2 3052 Key B for 5G, 1 x M.2 2230 Key E Slot For WiFi/BT

ƒ

Support Ubuntu, Ycoto Linux and Android

ƒ

Support I/O Expansions by UIO40-Express I/O boards, please refer to page

#3 for more information

RSB-3810

MediaTek Genio 1200 Cortex A78 & A55

2.5" SBC with UIO40-Express

Specifications

Form Factor

2.5" Single Board Computer with UIO40-Express for I/O Expansions

Processor System

CPU

MediaTek Genio 1200

Memory

Technology

LPDDR4 4000MT/s

Capacity

On-board 8GB

Flash

32GB eMMC Flash for O.S. and 8 MB SPI NOR Flash for board information

NPU

4.8 TOPS Neural Network performance

Graphics

HDMI

1 HDMI 2.0, 4K60

LVDS

1 dual channel LVDS

Ethernet

Chipset

RTL8153

Speed

2 10/100/1000 Mbps

WatchDog Timer

1~6553s, default 60s, power on/off 1s

TPM

TPM 2.0 (ST33HTPH2E32AHB8)

RTC

Yes

I/O

USB

1 USB3.0 Host, 1 USB2.0 Host

Audio

Mic-in, Line-Out Connectors

Serial Port

1 4 wires RS-232/422/485 by pin header + COM debug console

Camera Input

3 4-Lane MIPI-CSI2

UIO40-Express

2 USB2.0, 1 USB3.0, 10 GPIO, 2 UART), 1 I2C

Expansion

M.2

1 M.2 2230 Key E Slot / 1 M.2 3052 Key B Slot

SD Socket

1 Micro SD Socket

SIM Slot

1 Nano SIM Slot

Power

Power Supply Voltage

12V DC-IN by lockable DC Jack (default) or 2pin type connector

Environment

Operational Temperature

-20 ~ 60 °C

Operating Humidity

5%~95% Relative Humidity, non-condensing

Mechanical

Dimensions (W x D x H)

100 x 72 x 19 mm

Operating System

Ubuntu, Ycoto Linux and Android

Certifications

CE/FCC Class B

RoHS

COMPLIANT

2002/95/EC

All product specifications are subject to change without notice.

Last updated: 19-May-2022
